– 58 –
MODEL RAS-07CH1
1 PMRAS-202B 001 1 CABINET
2 PMRAS-07C1 011 1 LOW-COVER
3 PMRAS-07CH1 002 1 20W MOTOR
4 PMRAS-09C1 003 1 TANGENTIAL FLOW FAN
5 PMRAS-05C 013 1 P-BEA ASSEMBLY
6 PMRAS-05C 004 1 BEARING COVER
7 PMRAS-05C 005 1 FAN MOTOR SUPPORT
8 PMRAS-05C 006 1 ELECTRICAL COVER
9 PMRAS-05C 007 1 DRAIN PAN ASSEMBLY
10 PMRAS-252B 014 1 DRAIN HOSE
11 PMRAS-07CH1 005 1 FRONT COVER ASS'Y
12 PMRAS-05C 009 1 MOUNTING PLATE
13 PMRAS-07CH1 001 1 REMOTE CONTROL
14 PMRAS-07CH1 006 1 EVAPORATOR
15 PMRAS-5100C 006 1 UNION (2)
16 PMRAS-5100C 017 1 UNION (3)
17 PMRAS-05C 012 1 STEP MOTOR
18 PMRAS-07CH1 021 1 ELECTRICAL CASE
19 PMRAS-07CH1 22 1 ELECTRICAL COVER
20 PMRAS-07CH1 003 1 PWB (MAIN AND INDICATION)
23 PMRAS-07C1 006 2 TERMINAL (2P)
24 PMRAS-07C1 007 1 TERMINAL BOARD (3P)
26 PMRAS-07CH1 007 1 ZR-POST-5P
27 PMRAS-07CH1 008 1 TRANSISTOR (2SA1121SC)
28 PMRAS-07CH1 09 1 IF-MODULE
29 PMRAS-07CH1 010 1 ZENER DIODE (RLZ10)
30 PMRAS-07CH1 011 1 ZENER DIODE (RZL24)
31 PMRAS-07CH1 012 1 DIODE (DIFL20U)
32 PMRAS-07CH1 013 1 DIODE (G4DL6140)
33 PMRAS-07CH1 014 1 BUZZER (PKM13EPP)
34 PMRAS-07CH1 015 1 COIL (82µH, 1.3A)
35 PMRAS-07CH1 016 1 COIL (450µH, 1.5A)
36 PMRAS-07CH1 017 1 CAPACITOR (470µF, 50V)
37 PMRAS-07CH1 018 1 CAPACITOR (220µF, 50V)
PART N0.
RAS-07CH1
NO.
Q’TY / UNIT
PARTS NAME
