Hitachi RAD-70PPD - Names and Functions of each Part; Indoor Unit; Outdoor Unit

– 4 –
NAMES AND FUNCTIONS OF EACH PART
Suction grille
Discharge grille
FULL DUCT
SEMI DUCT NON DUCT
Air defl ector
DRAIN PIPE
Condensed water drain to outside.
CONNECTING CORD
AIR INLET (BACK, LEFT SIDE)
AIR OUTLET
DRAIN PIPE
Condensed water drain to outside.
CONNECTING CORD
AIR INLET (BACK, LEFT SIDE)
AIR OUTLET
Discharge grille
Discharge grille
INDOOR UNIT
OUTDOOR UNIT
MODEL NAME AND DIMENSIONS
WIDTH (mm)
900
850
850
MODEL
RAD-50PPD / RAD-60PPD / RAD-70PPD
RAC-50NPD / RAC-60NPD
RAC-70NPD
HEIGHT (mm)
270
750
800
DEPTH (mm)
720
298
298
RAC-50NPD/
RAC-60NPD
RAC-70NPD
