– 4 –
INDOOR UNIT
NAMES AND FUNCTIONS OF EACH PART
Pre-Þ lter
To prevent dust from coming into the indoor unit.
(Refer page 10)
Front panel
Indoor unit indicators
Light indicator showing the operating condition.
(Refer page 5)
Horizontal deß ector
●
Vertical deß ector
(Air Outlet)
Remote controller
Send out operation signal to the indoor unit. So as
to operate the whole unit.
(Refer Remote control manual)
MODEL NAME AND DIMENSIONS
● Air purifying Þ lters are not washable. It is recommended to use vacuum to clean it. It can be use
for 1 year time. Type number for this air purifying Þ lter is <SPX-CFH22>. Please use this number
for ordering when you want to replace it.
NOTE
RAK-18QPA/RAK-25QPA/RAK-35QPA/RAK-50QPA
WIDTH (mm)MODEL HEIGHT (mm)
DEPTH (mm)
790
300
230
