Figure showing the installation of lndoor unit
MODEL RAK-15Q PB
RAK-18RPB
above
50mm
above 50mm
above 50mm
mm003 tuoba
about 450mm
dneb ton tsum
The indoor piping should be
insulated with the enclosed
insulation pipe. (If the insulator is
insufficient, please use commercial
products.)
Be sure to
completely
seal any gap
with putty.
2300 mm or more
Plug
Maximum pipe length 20m
Minimum pipe length 3m
RAK-25RPB
- 7 -
