– 4 –
INDOOR UNIT
OUTDOOR UNIT
WIDTH (mm)
1150
850
MODEL
RAS-18CX9KS2/RAS-24CX9KS2
RAC-18CX9/RAC-24CX9
HEIGHT (mm)
333
650
DEPTH (mm)
245
298
MODEL NAME AND DIMENSIONS
NAMES AND FUNCTIONS OF EACH PART
AIR FILTER
To prevent dust from coming into the
indoor unit.
(Refer page 23)
FRONT PANEL (AIR INLET).
INDOOR UNIT INDICATORS
Light indicator showing the operating
condition.
(Refer page 5)
HORIZONTAL DEFLECTOR
●
VERTICAL DEFLECTOR (AIR
OUTLET)
(Refer page 18)
REMOTE CONTROLLER
Send out operation signal to the indoor
unit. So as to operate the whole unit.
(Refer page 6)
●
Drain pipe
Condensed water drain to outside.
Connecting cord and insulation pipe for piping
Air inlet (Back and Left side)
Air outlet
