1.2.3 Combination of outdoor units FSXN1E
The power range of the RAS-(8-54)FSXN1E outdoor units is obtained by applying one unit (RAS-(8-16)FSXN1E) or by the combina-
tion of two or three outdoor units (RAS-(18-54)FSXN1E), depending on the instructions in the following tables.
This outdoor unit series FSXN1E can build the capacity from 8 to 54HP by combining maximum 4 outdoor units from 8 to 16HP.

Base units
HP 8 10 12 14 16
Model
RAS-8FSXN1E RAS-10FSXN1E RAS-12FSXN1E RAS-14FSXN1E RAS-16FSXN1E

Combination of base units
HP 16-P / 18 20 22 24 26
Model
RAS-16FSXN1E-P
RAS-18FSXN1E
RAS-20FSXN1E RAS-22FSXN1E RAS-24FSXN1E RAS-26FSXN1E
Combination
RAS-8FSXN1E RAS-8FSXN1E RAS-8FSXN1E RAS-10FSXN1E RAS-12FSXN1E
RAS-10FSXN1E RAS-12FSXN1E RAS-14FSXN1E RAS-14FSXN1E RAS-14FSXN1E
HP 28 30 32 32-P / 34 36
Model
RAS-28FSXN1E RAS-30FSXN1E RAS-32FSXN1E
RAS-32FSXN1E-P
RAS-34FSXN1E
RAS-36FSXN1E
Combination
RAS-14FSXN1E RAS-14FSXN1E RAS-16FSXN1E RAS-10FSXN1E RAS-12FSXN1E
RAS-14FSXN1E RAS-16FSXN1E RAS-16FSXN1E RAS-12FSXN1E RAS-12FSXN1E
- - - RAS-12FSXN1E RAS-12FSXN1E
HP 38 40 42 44 46
Model
RAS-38FSXN1E RAS-40FSXN1E RAS-42FSXN1E RAS-44FSXN1E RAS-46FSXN1E
Combination
RAS-12FSXN1E RAS-12FSXN1E RAS-12FSXN1E RAS-12FSXN1E RAS-14FSXN1E
RAS-12FSXN1E RAS-12FSXN1E RAS-14FSXN1E RAS-16FSXN1E RAS-16FSXN1E
RAS-14FSXN1E RAS-16FSXN1E RAS-16FSXN1E RAS-16FSXN1E RAS-16FSXN1E
HP 48 50 52 54
Model
RAS-48FSXN1E RAS-50FSXN1E RAS-52FSXN1E RAS-54FSXN1E
Combination
RAS-16FSXN1E RAS-10FSXN1E RAS-12FSXN1E RAS-12FSXN1E
RAS-16FSXN1E RAS-12FSXN1E RAS-12FSXN1E RAS-12FSXN1E
RAS-16FSXN1E RAS-14FSXN1E RAS-14FSXN1E RAS-14FSXN1E
- RAS-14FSXN1E RAS-14FSXN1E RAS-16FSXN1E
1.2.4 Combination of outdoor units FSXNH
The power range of the RAS-(5-36)FSXNH(E)(-P) outdoor units is obtained by applying one unit (RAS-(5-12)FSXNH(E)) or by the
combination of two or three outdoor units (RAS-(14-36)FSXNH(E)), depending on the instructions in the following tables.
This outdoor unit series FSXNH(E) (high efciency type) can build the capacity from 5 to 36HP by combining maximum 3 outdoor units
from 5 to 12HP.

Base units
HP 5 6 8 10 12
Model RAS-5FSXNH(E) RAS-6FSXNH(E) RAS-8FSXNH(E) RAS-10FSXNH(E) RAS-12FSXNH(E)
2
PMML0294A rev.2 - 07/2014
General information
PMML0294A_rev.2_02-2014.indb 2 14/07/2014 12:27:58
