1.4 PURPOSE OF THIS MANUAL
The air conditioning system should only be installed by qualiîš¿ed
personnel, with the necessary resources, tools and equipment,
who are familiar with the safety procedures required to success-
fully carry out the installation.
PLEASE READ AND FAMILIARISE YOURSELF WITH THE
MANUAL BEFORE STARTING WORK ON THE INSTALLATION
OF THE AIR CONDITIONING SYSTEM. Failure to observe the
instructions for installation, use and operation described in this
Manual may result in operating failure including potentially seri-
ous faults, or even the destruction of the air conditioning system.
It is assumed that the air conditioning system will be installed and
maintained by responsible personnel trained for the purpose. If
this is not the case, the customer should include all the safety,
caution and operating signs in the native language of the person-
nel responsible.
Do not install the unit in the following places, as this may lead to
a îš¿re, deformities, rusting or faults:
• Places where oil is present (including oil for machinery).
• Places with a high concentration of sulphurous gas, such as
spas.
• Places where ammable gases may be generated or circu-
late.
• Places with a saline, acidic or alkaline atmosphere.
Do not install the unit in places where silicon gas is present. Any
silicon gas deposited on the surface of the heat exchanger will re-
pel water. As a result, the condensate water will splash out of the
collection tray and into the electrical box. Water leaks or electrical
faults may eventually be caused.
Do not install the unit in a place where the current of expelled
air directly affects animals or plants as they could be adversely
affected.
1.5 WORKING RANGE
This heat pump and heat recovery system has been designed
for the following temperatures. Use the system within this range.
The system can provide refrigeration or heating or can provide
refrigeration and heating at the same time.
The following table indicates the temperature range.
Mode Cooling Heating
Indoor
temperature
Min. 21 ºC DB / 15 ºC WB 15 ºC DB
Max. 32 ºC DB / 23 ºC WB 27 ºC DB
Outdoor
temperature
Min. -5 ºC DB
(1)
-20 ºC WB
(2)
Max. 43 ºC DB 15 ºC WB
(1) (10 – -5) ºC DB, operating control range.
(2) (-12 – -20) ºC WB, operating control range.
NOTE
DB: dry bulb; WB: wet bulb.
2 REMOTE CONTROL OPERATION
There are two types of wired remote control: PC-ART and PC-ARF.
Refer to the Installation and Operations Manual of the remote controller.
5
PMML0294A rev.2 - 07/2014
Remote control operation
PMML0294A_rev.2_02-2014.indb 5 14/07/2014 12:27:59
