SERVICE MANUAL
PRIMAIRY
LARGE SINGLE SPLIT
DC-INVERTER SERIES
MODELS
MODELS
HS2021393HA
SM)-210131
INDOOR UNITS
OUTDOOR UNITS
DUCTED
RPIL-1.0PNN1DH
RPIL-1.5PNN1DH
RPIL-2.0PNN1DH
RPIM-3.0PNN1DH
RPIM-4.0PNN1DH
CASSETTE
RCIM-1.0PNN1DH
RCIM-1.5PNN1DH
RCI-2.0PNN1DH
RCI-3.0PNN1DH
RCI-4.0PNN1DH
RAS-1.0PNNBDH1
RAS-1.5PNNBDH1
RAS-2.0PNNBDH1
RAS-3.0PNNBDH1
RAS-4.0PNNBDH1
