5K320 SATA OEM Specification
162
14.43 Write Buffer (E8h)
Command Block Output Registers Command Block Input Registers
Register 7 6 5 4 3 2 1 0 Register 7 6 5 4 3 2 1 0
Data - - - - - - - - Data - - - - - - - -
Feature - - - - - - - - Error ...See Below...
Sector Count - - - - - - - - Sector Count - - - - - - - -
LBA Low - - - - - - - - LBA Low - - - - - - - -
LBA Mid - - - - - - - - LBA Mid - - - - - - - -
LBA High - - - - - - - - LBA High - - - - - - - -
Device - - - - - - - - Device - - - - - - - -
Command 1 1 1 0 1 0 0 0 Status ...See Below...
Error Register Status Register
7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0
CRC UNC 0 IDN 0 ABT T0N AM
N
BSY RDY DF DSC DRQ COR IDX ERR
0 0 0 0 0 V 0 0 0 V 0 - - 0 0 V
Table 127 Write Buffer Command (E8h)
The Write Buffer command transfers a sector of data from the host to the sector buffer of the
device. The sectors of data are transferred through the Data Register 16 bits at a time.
The Read Buffer and Write Buffer commands are synchronized such that sequential Write Buffer
and Read Buffer commands access the same 512 byte within the buffer.
