OPERATOR'S STATION
1-6
•
Auto-Idle Display (2)
When selecting auto-idle from the switch panel, auto-idle
display (2) is displayed.
When the key is turned ON, the data blinks for 10 seconds.

Overload Alarm Display (3) (optional)

T1V1-05-02-002

The system measures the load of suspended load from the
bottom pressure of boom cylinder. When overload is de-
tected, an alarm is displayed.
•
Preheat Display (6)
While the current is being supplied to the glow plug, the
indicator is displayed.
•
Fuel Rate Display (13)
Fuel consumption is displayed (Reference value).
2 6
13
3
M1U1-01-113
To Next Page
