MAINTENANCE
7-59
Replace Fuel Pre-Filter Element
---every 1000 hours or when fuel filter clogging lamp
is lit
IMPORTANT:
Be sure to use only genuine Hitachi elements for
the fuel main filter element and the pre-filter
element. Failure to do so may deteriorate the engine
performance and/or shorten the engine service life.
Please be noted that all engine failures caused by
using other manufacturers' elements are excluded
from Hitachi Warranty Policy.
Take care not to allow dirt and/or water to enter the
fuel tank.
Procedures:
1. Close cock (1) on the bottom of the fuel tank.
(to next page)
1
MDAA-07-007
Pre-Filter
Pre-Filter
Main Filter
Main Filter
MDCN-07-032
ZX225US-5B, 225USLC-5B
ZX135US-5B
M1U4-07-029
