OPERATOR'S STATION
1-72
M1U1-01-056
4
3
2
1
M1CC-01-022
M178-01-061
Cab Door Window
REMOVING AND STORING LOWER FRONT
WINDOW
CAUTION: Take care not to pinch yours fingers when
handling the lower front window.
1. Open the upper front window beforehand when remov-
ing the lower front window.
2. While pulling the lower front widow inward, raise it to
remove.
3. Store the removed windowpane in the storing position.
After inserting the windowpane into rubbers (2 and 3),
slide it sideways securely into rubber (1). Then, push fas-
tener (4) to lock.
OPENING SIDE WINDOWS
Opening Cab Door Window
Slide rear pane to the front.
To Next Page
