SPECIFICATIONS
12-9
SHOE TYPES AND APPLICATIONS
ZX130LCN-3
Shoe Width
500 mm (20”)
Grouser Shoe
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
500 mm (20”)
Pad Crawler
Shoe
Application
For Ordinary
Ground
For weak
Footing
For weak
Footing
For weak
Footing
For Paved
Road
Operating Weight kg
(lb)
12700
(28000)
13000
(28700)
13200
(29100)
13400
(29500)
12800
(28200)
Base Machine Weight kg
(lb)
10000
(22100)
10300
(22700)
10500
(23200)
10700
(23600)
10100
(22300)
Cab Height mm
(ft•in)
2740
(9’0”)
2740
(9’0”)
2740
(9’0”)
2740
(9’0”)
2780
(9’1”)
Minimum Ground mm
Clearance (ft•in)
440440
(1’5”)
440440
(1’5”)
440440
(1’5”)
440440
(1’5”)
500
(1’8”)
Undercarriage mm
Length (ft•in)
3750
(12’4”)
3750
(12’4”)
3750
(12’4”)
3750
(12’4”)
3830
(12’7”)
Undercarriage Width mm
(ft•in)
2490
(8’2”)
2590
(8’6”)
2690
(8’10”)
2790
(9’2”)
2490
(8’2”)
Ground Pressure
38 kPa
(0.39 kgf/cm
2
,
5.5 psi)
32 kPa
(0.33 kgf/cm
2
,
4.6 psi)
28 kPa
(0.29 kgf/cm
2
,
4.1 psi)
25 kPa
(0.25 kgf/cm
2
,
3.6 psi)
38 kPa
(0.39 kgf/cm
2
,
5.5 psi)
NOTE: • The specifications for the front-end attachment are for a 2.52 m (8 ft 3 in) arm with PCSA 0.50 m
3
(0.65 yd
3
) stan-
dards bucket.
• 600 mm (24 in), 700 mm (28 in), 800 mm (31 in) grouser shoe, 500 mm (20 in) pad crawler shoe should not be used
on gravel or rocky ground.
• The dimensions do not include the height of the shoe lug.
