OPERATOR'S STATION
1-35
Auto-Control: OFF
Set automatic switching function of images between moni-
tor unit and back monitor when traveling to OFF.
1. When the basic screen displays, push the menu key and
display main menu.
2. Select back monitor settings from main menu by using
keys 1 and 2. Push the determination key. Then, the back
monitor settings screen displays.
3. Select auto-control by using keys 1 and 2. Push the deter-
mination key. Then, auto-control is set to OFF.
NOTE: When pushing the back key, return to the previous
screen.
4. Push key 6 , and return to the basic screen.
Key 6
Menu Key
T1V1-05-01-123
Basic Screen
T1V5-05-01-173
Back Key
T1V5-05-01-174
Back KeyDetermination KeyKey 2Key 1
T1V5-05-01-118
Back KeyDetermination KeyKey 2Key 1
