HITEC X2 AC Plus Black Edition User Manual

8
Product Layout
Dot Matrix 128 x 64
LCD Display
Output Socket
4mm Banana Plug
Temperature
Sensor Port
Output Socket
4mm Banana Plug
Balance Lead Socket
Cooling Fan
Micro USB Port for PC Link &
rmware upgrade
Alter Values, See the Status
of Individual Cells in Balance
Charge Mode
Scroll Through the
Main Menu, Stop Any
Charge Processes
Switch from
Channel A to B or
Channel B to A
Speaker
AC Input
100-240V
DC Input: 11-18V
DC Output: 13.8V
DC Power
LED Light
Resume or Start
Charge Processes
Balance Lead Socket
Temperature Sensor Port
USB Port

HITEC X2 AC Plus Black Edition Specifications

General

Brand	HITEC
Model	X2 AC Plus Black Edition
Category	Power Supply
Language	English
