About PWS700T
B.9 Downloading Application
To make the 700T Workstation ready for receiving your
application data downloaded from a PC or another 700T, press
the Download Application button on System Menu. The
Workstation displays the message "Waiting for
downloading...” when it is ready.
After downloading, the System Menu is active again.
You should have a cable with the following connection for
the download.
PWS to PC's 9-pin
connector PWS to
PC's 25-pin connector
PWS-COM2 PC COM RS232C
25-pin female --CABLE---25-pin female
Warning: To avoid electric
shock, be sure to switch off
the power when connecting the
communication/download cable to the PWS unit .
PWS-COM2 PC COM RS232C
25-pin female --CABLE--- 9-pin female
Hitech Electronics Corp.
B-11
