HLC-200A
HITROL CO., LTD. 3
Overview
Characteristic
Operating
and
Principles
■ Compact size.
■ Easy to install DIN Rail type.
■ Socket structure type for easy installation and removal of the product.
■ Operation can be checked with LED lighting. (High : Red, Low : Green)
■ Sensitivity adjustment function can be used in the field when it operates sensitively
according to the measurement object.
HLC-200A is a Level Control & Alarm Unit that controls and alarms by combining with
the level sensors (HE, HQ, HR Type) of the storage tank.
The signal of the level sensor can control the upper and lower alarm of liquid and
automatic supply of liquid through HLC-200A, and the product can be installed inside the
control panel.
When the liquid in the tank is detected by the level sensor connected to the HLC-200A,
a leakage current flows and the transistor operates through the leakage current detection
circuit. Accordingly, relay contact point can be changed and used as alarm or control signal.
HLC-200A Body
HLC-200A Socket
Socket Locker
DIN-Rail Mounting Button
Unit : mm
Serial No.
