Hive Bridge - Page 5

Gettin Started
2
3
Thread the Cat-5 (ethernet) cable throu h one of the lands in
the bottom of the inverter and plu
into the RJ-45 connector
Connect the other end of the cable to the RJ-45 connector on
the Hive Brid e
labelled RS485. Try and avoid sharp bends in the routing.
