8 Technical Data
AT 112 A:
Inputs / Outputs: Line In L/ R: XLR female ( 1 = ground; 2 = +; 3 = - )
Input: electronically balanced & floating
Input impedance: 47 kΩ
Sensitivity: 0 dB
Peak input level: +24 dB
Parallel Out L/ R: XLR male ( 1 = ground; 2 = +; 3 = - )
Speakers: 1x 12" B&C Speaker, 1x 1" BMS driver, 60° x 40° horn
Power output: 400 watts (active)
Sound pressure level 1W/1m: 106 dB (half-space)
Max. sound pressure level / 1m: 129 dB @ 10% THD (half-space)
Directivity: Horizontal: ± 30° ; 2kHz - 20 kHz
Vertical: ± 20° ; 3kHz - 20 kHz
Frequency response: 100 Hz - 20 kHz; ± 3 dB
Crossover frequencies: 12"/1": 1.3 kHz, 12 dB/octave
Low-cut: (Sat/Full-range switch), 100 Hz, 24 dB/octave
Weight: 29 kg / 63.8 lbs.
Dimensions (WxHxD: 40 x 65 x 42 cm - 15 3/4" x 25 5/8" x 16 1/2"
AT 115 SUB A:
Inputs / Outputs: Line In L/ R: XLR female ( 1 = ground; 2 = +; 3 = - )
Input: electronically balanced & floating
Input impedance: 47 kΩ
Sensitivity: 0 dB
Peak input level: +24 dB
Parallel Out L/ R: XLR male ( 1 = ground; 2 = +; 3 = - )
Speaker: 1x 15" HK AUDIO custom
Power output: 400 watts (active)
Sound pressure level 1W/1m: ^ 104 dB (half-space)
Max. sound pressure level / 1m: 126 dB @ 10% THD (half-space)
Frequency response: 40 Hz - 130 Hz
Crossover: 130 Hz, 24 dB/octave
Weight: 35 kg / 77 lbs.
Dimensions (WxHxD): 48 x 65 x 64 cm - 18 7/8" x 25 5/8" x 25 1/8" incl. wheels
General electrical data:
Protection class 1 (protectively grounded/earthed)
Mains voltage 230V: Power fuse T 2A (AT 112 A and AT 115 Sub A)
Mains voltage 117V: Power fuse T 4A or SB 4A (AT 112 A &. AT 115 Sub A)
Mains voltage 100V: Power fuse T 4A (AT 112 A and AT 115 Sub A)
Max. current consumption: 2.7A @230 volts
Max. power consumption: 630 VA
Mains voltage range: +/- 10%
Ambient temperature range: -10°C to + 60°C
Internal fuses: 4x T 4A’s
Covers are available separately for the ACTOR system’s
subwoofer and top unit.
