LINEAR 5 2.0
7
7 Technical Specifi cations
MODEL L5 112 FA L5 112 XA L5 115 FA
Frequency response +/– 3 dB 64 Hz – 18 kHz 100 Hz – 18 kHz 57 Hz – 18 kHz
Frequency response –10 dB 57 Hz – 20 kHz 72 Hz – 20 kHz 48 Hz – 20 kHz
Axial sensitivity HF, 1W/1m 110 dB full-space,
116 dB half-space
110 dB full-space ,
116 dB half-space
110 dB full-space,
116 dB half-space
Axial sensitivity LF, 1W/1m 98 dB full-space,
104 dB half-space
98 dB full-space,
104 dB half-space
100 dB full-space,
106 dB half-space
Max. SPL@10% THD 127dB half-space 128 dB half-space 128 dB half-space
Max. SPL Peak@10% THD 135 dB half-space 136 dB half-space 137 dB half-space
Max. SPL Calc. 137 dB half-space 137 dB half-space 138 dB half-space
Amp/type Class D bi-amped Class D bi-amped Class D bi-amped
Power output 1,000 W 1,000 W 1,000 W
Amp to driver 350 W @ 4 Ohms 350 W @ 4 Ohms 350 W @ 4 Ohms
Amp to woofer 650 W @ 4 Ohms 650 W @ 4 Ohms 650 W @ 4 Ohms
Protective circuits, amp Under-voltage, thermal, short
circuit, and over-current protection
Under-voltage, thermal, short
circuit, and over-current protection
Under-voltage, thermal, short circuit,
and over-current protection
Protective circuits, speakers Subsonic 24 dB/oct. peak limiter Subsonic 24 dB/oct. peak limiter Subsonic 24 dB/oct. peak limiter
Power consumption 3 A/230 V nominal pursuant to
EN600056
3 A/230 V nominal pursuant to
EN600056
3 A/230 V nominal pursuant to
EN600056
Input sensitivity +4 dBu @ Gain center-notched/ L5
System Level
+4 dBu @ Gain center-notched/ L5
System Level
+4 dBu @ Gain center-notched/ L5
System Level
Audio ports 2x XLR In, 2x XLR-Thru,
1x XLR Mix Out
2x XLR In, 2x XLR-Thru,
1x XLR Mix Out
2x XLR In, 2x XLR-Thru,
1x XLR Mix Out
Mains connector 1x IEC socket with V-Lock cord
retainer
1x IEC socket with V-Lock cord
retainer
1x IEC socket with V-Lock cord
retainer
Bass woofer 1x 12" with 2.5" voice coil (4 Ohms) 1x 12" with 2.5" voice coil (4 Ohms) 1x 15" with 3" voice coil (4 Ohms)
HF driver 1" with 1.75" voice coil (16 Ohms) 1" with 1.75" voice coil (16 Ohms) 1" with 1.75" voice coil (16 Ohms)
Horn directivity 60°–90° (asy.) x 55° CD horn,
rotatable
60° x 40° CD horn, rotatable 60°–90° (asy.) x 55° CD horn,
rotatable
X-over frequency 1.65 kHz, 24 dB/oct. active 1.65 kHz, 24 dB/oct. active 1.65 kHz, 24 dB/oct. active
Pole mount DuoTilt™ 3/7 DuoTilt™ 3/7 DuoTilt™ 3/7
Rigging/ pick points 3x M8 3x M8 3x M8
Grips 2, integrated 2, integrated 2, integrated
Optional accessories Protective cover, TB-1, AP-8,
TiltUnit
Protective cover, AP-8, TiltUnit Protective cover, TB-1, AP-8, TiltUnit
Housing Hybrid (birch multiplex / MDF) Hybrid (birch multiplex / MDF) Hybrid (birch multiplex / MDF)
Front grille 2 mm metal grille backed with
black acoustic foam
2 mm metal grille backed with
black acoustic foam
2 mm metal grille backed with black
acoustic foam
Finish Acrylic enamel, black Acrylic enamel, black Acrylic enamel, black
Dimensions (WxHxD) 37 x 66.8 x 36.5 cm 37 x 66.8 x 30 cm 44.9 x 70.8 x 45 cm
 14-9/16 x 26-19/64 x 14-3/8" 14-9/16 x 26-19/64 x 11-13/16" 17-43/64 x 27-7/8 x 17-23/32"
Weight 23.9 kg / 52.7 lbs. 21.1 kg / 46.5 lbs. 30.7 kg / 67.7 lbs.
