LUCAS 2K15/2K18 1.0
31
7 Datos técnicos
Sistema LUCAS 2K
Potencia total (RMS)¹ 670 W Clase D
Calculated Peak-Power 2000 W
Características DSP Filtrado FIR, Filtro subsónico de 24 dB,
limitador de pico y RMS
Carcasa MDF
Superfi cie Laca acrílica, negra
Rejilla frontal Rejilla metálica con espuma negra acústica
Accesorios opcionales LUCAS 2K ROLLER BAG, SPEAKER STAND
ADD-ON, SPEAKER STAND STRETCH
COVER (Cubierta de trípode, husse)
Peso total (2K15) 53,0 kg / 116,9 lbs.
Peso total (2K18) 65,4 kg / 144,2 lbs.
Subwoofer LUCAS 2K15
Máx. SPL Peak² 129 dB
Respuesta de frecuencia
+/- 5 dB
44 Hz – 130 Hz
Entradas 2x toma combinada jack/XLR
Salidas 2x XLR Thru, 2x Satellites Out (Speakon)
Altavoz de graves 1x 15"
Brida para soporte en
altura
1x M20 (K&M)
Asas 2x HK Audio MultiGrip
Dimensiones (AxAxP) 48 x 48,5 x 59,5 cm
Peso 30,2 kg / 66,6 lbs.
LUCAS 2K18 Subwoofer
Máx. SPL Peak² 128 dB
Respuesta de frecuencia
+/- 5 dB
39 Hz – 130 Hz
Entradas 2x toma combinada jack/XLR
Salidas 2x XLR Thru, 2x Satellites Out (Speakon)
Altavoz de graves 1x 18"
Brida para soporte en
altura
1x M20 (K&M)
Asas 2x HK Audio MultiGrip
Dimensiones (AxAxP) 51 x 67 x 72,5 cm
Peso 42,6 kg / 93,9 lbs.
Satélite LUCAS 2K
Máx. SPL Peak² 127 dB
Respuesta de frecuencia
+/- 5 dB
118 Hz – 18 kHz
Altavoz de medios 1x 8"
Altavoz de agudos 1"
Irradiación horizontal/
vertical
90° x 55°
Entradas Speaker In (Speakon)
Brida para soporte en
altura
HK Audio MonoTilt 3°
Asas 1x HK Audio ErgoGrip™ fresado
Dimensiones (AxAxP) 26,5 x 41,5 x 29,5 cm
Peso 11,4 kg / 25,1 lbs.
¹ Valor RMS por corto tiempo, medido utilizando una señal de ráfaga senoidal con una sincronización
de 1/4 y un factor de cresta resultante de 9 dB con una frecuencia representativa para el sistema
² @10% THD, Halfspace
Datos técnicos generales
Corriente de pico 2,6 A / 100-120 V AC • 1,4 A / 220-240 V AC
Corriente de conexión 39 A con 120 V y 230 V
8 Aplicaciones
Encontrará ejemplos de conexión para cableado a partir de la
página 32.
LR
LR
Gain Bass = –6 dB
X-Over Bass = 100 Hz
Phase = 0°
Line
Mic
Gain A
Input A
+6 dB
0 dB
Line
Mic
Gain A
Input A
+6 dB
0 dB
LUCAS 2K
+ Monitoring
+ L SUB
LUCAS 2K
Subwoofer
L SUB
Extension
LUCAS 2K
Satellite
LUCAS 2K
Satellite
Mixer
L5 112 XA L5 112 XA
Input
LR
LR
Thru
Satellites Out
LR
Input
LR
Gain Bass
+6 dB–6 dB
0 dB
180°
120 Hz
100 Hz
Configuration X-Over Bass Phase
LR
Thru
Serial No.
2
1
21
Input
LUCAS 2K
SATELLITE
8 Ohms
300 W Program
Serial No.
2
1
21
Input
LUCAS 2K
SATELLITE
8 Ohms
300 W Program
Sub
+6 dB
0 dB
Flat
Bass Boost
Sub = 0 dB
Input = LineInput = Line
Bass Boost = On
