HK Audio LUCAS 2K15 - 2. DJ + Bass Extension

LUCAS 2K15/2K18 1.0
33
2. DJ + Bass Extension:
LUCAS 2K15 + L SUB 1500 / LUCAS 2K18 + L SUB 1800
LR
Gain Bass = –6 dB
X-Over Bass = 100 Hz
Phase = 0°
LUCAS 2K + L SUB
LUCAS 2K
Subwoofer
L SUB
Extension
LUCAS 2K
Satellite
LUCAS 2K
Satellite
DJ Workstation
Input
LR
LR
Thru
Satellites Out
LR
Input
LR
Gain Bass
+6 dB–6 dB
0 dB
180°
0°
120 Hz
100 Hz
Configuration X-Over Bass Phase
Serial No.
2
1
21
Input
LUCAS 2K
SATELLITE
8 Ohms
300 W Program
Serial No.
2
1
21
Input
LUCAS 2K
SATELLITE
8 Ohms
300 W Program
Sub
+6 dB
0 dB
Flat
Bass Boost
Sub = 0 dB
Bass Boost = On
• Application Samples
