Chick-fil-A Ion/EOS Installation
Scope of Work
• Contact GC’s Superintendent at least 24 hours in advance of install to confirm
schedule and ETA
• Base station shall be mounted on top of DT J-box and over cover plate located on
bulkhead facing DT window (inside drive-thru area) – it is recommended you install
a 1” grommet in cover plate to protect wiring from base to J-box (Ask GC to notch
the plate for cables)
• Pull new cable for both systems!
Do not use existing D15 harness for the IC300!
• IC300 should be mounted flat on the wall (no pedestal mount) near the J-box with
conduit connected to base station as shown on drawing – IC300 will always be
connected to inside lane (lane 1)
• Install/interface with cabled intercom
• Install DM5 and SP10 speaker
