04-5
Warnings for changing the tire:
Onlyusethespecicallydesignated
jack for the corresponding frame
parts.
For example, on the axle pipe corre-
sponding to the swinging lever group
or on the stringer in the area of the
axle fasteners.
Damage or even an accident result-
ing from the vehicle's toppling over
can occur if the jack is applied to
other parts of the vehicle.
The jack is only to be used for
changing tires. It may not be used for
working under the vehicle!
The rotating stanchions may not be
used as a jack!
The jack is not part of the standard
equipment in this series, and is there
fore not included.
After changing the tire, the wheel
screws must be examined (after a 50
km drive) to ensure that they are tight
enough (tighten if necessary).
Changing the wheel
• Set the corresponding jack onto the axle pipe
of the swinging lever group or on the longitu
dinal beam in the area of the axle attachments
of the wheel to be changed.
• On campers with a double axle, always set
the jack onto the rear axle; a hydraulic jack
(not included) is recommended.
• If the vehicle is parked on soft ground, lay a
stable reinforcement under jack (i.e., a board).
• Lift the vehicle until the wheel is 2 or 3 cm off
the ground.
• Reposition the ratchet jack handle if it should
slant when you jack up the vehicle.
• Remove the wheel fastening screws and the
wheel.
• Attach the spare tire to the hub and adjust it.
• Reattach the wheel screws and tighten them
lightly over the transversal.
