Hobie Kit III User Manual

5
1.
2.
1.
There are plugs for the wire to
come out on either side of the
boat if you prefer a right/left side
screen location.
NOTE: Some plugs are located in
cup holders and mesh pockets.
2
1. Run the
cable into
the plug just
behind the
transducer
scupper.
3
2. Lead the cable through
the insde of the boat and
exit the cable out through
the thru-hull fitting.
(See next page for install-
ing Thru-Hull Pugs)
Running Transducer & Power Cable
