ELECTRIC BARBECUE 2 IN 1
Assemble the zinc plate (D) on the upper
tray (A) by tting it to the screw on the tray
(A) and secure both parts with the nut (M)
provided.
Also t the metal bar (C) in the side holes of
the zinc plate (D) and the upper tray (A) as
shown in the gure on the side.
Turn the set of trays (A) and plate (D)
upside down and assemble the rubber
sockets (N) at both ends of the metal bar
(C) as shown in the gure on the side.
In the gure on the left side you can see in
detail the tting of the rubber sockets (N) at
the end of the metal bar (C).
After the sockets (N) are assembled, turn
the entire assembly to the correct position
again.
Insert or set of control panel, heating
element (resistance) and power cord
(B) on the tray (A) and plate (D) already
assembled.
After assembling the control panel, heat-
ing element (resistance) and power cord
(B), the appliance must be as shown in the
gure on the side.
