6. PRODUCT SPECIFICATION
1. Front and rear shields
2. Motor
3. Fan blade
4. Control panel
5. Telescopic tube
6. Height regulation ring
7. Base tube
8. Remote control (requires 2 AAA batteries)
9. Base
1
2
3
4
5
6
7
9
8
10. Swing mode indicator
11. Mode indicators: night, natural, normal
(default, no indicator)
12. Fan speed indicators: high, medium, low
13. Timer control indicators: 0.5 hour,
1 hour, 2 hours, 4 hours
14. ON/OFF and SPEED button
15. MODE button
16. TIMER button
17. SWING button
Control panel
14
16
10 11 12 13
15
17
