10
Adres producenta/ Adresse des Herstellers/ Manufacturer’s Address/ Адрес производителя
GTV Poland Sp. z o.o. Sp. k., ul. Przejazdowa 21, 05-800 Pruszków
Capacitance
6nF 1pF
±(3.0%+5d)
60mF
60nF 10pF
600nF 100pF
6uF 1nF
60uF 10nF
600uF 100nF ±(3.5%+5d)
6mF 1uF ±(5.0%+6d)
60mF 10uF ±(10%+8d)
6. FREQUENCY
Function Range Resolution Accuracy Max
Frequency
999.9Hz 0.1Hz
±(1.0%+5d)
20mHz
9.999kHz 1Hz
99.99kHz 10Hz
999.9kHz 100Hz ±(2.0%+5d)
9.999mHz 1kHz ±(3.0%+5d)
20.00mHz 10kHz ±(4.0%+10d)
6. Maintanance
6.1. Battery replacement
To avoid electric shock or injury caused by an incorrect reading, replace the battery immediately when the instrument display shows
the „
”. Before opening the battery cover and replacing the batteries, it is necessary to switch off and check whether the testers
have been disconnected from the circuit being measured.
Replace the battery according to the following steps:
1. Disconnect the power supply to the instrument.
2. Pull all test plugs out of the input socket.
3. Loosen the screws securing the battery cover.
4. Remove battery cover.
5. Remove old battery.
6. Replace with a new AAA 2 x 1.5 V battery.
7. Place the battery cover and tighten the screws.
6.2. Fuse replacement
1. Replace tester probes and turn off multimeter
2. Use screwdriver to open back cover and take out broken fuse
3. Replace fuse and screw back plate on place.
6.3. Maintanance
To clean device use soft cloth. Do not use solvents nor abrasives which could cause corrosion or damage of body.
