5.2 ELECTRICAL SPECYFICATION
1. CONTINUITY AND NCV
Continuity test √
NCV √
2. VOLTAGE DC/AC
Function Range Resolution Accuracy Max
DC Voltage
(V)
4V 0.001V
± (0.8%+3d)
600V
40V 0.01V
400V 0.1V
600V 1V ± (1%+3d)
AC Voltage
(V)
4V 0.001V
±(1%+3d)
600V
40V 0.01V
400V 0.1V
600V 1V ± (1.2%+5d)
Note: To prevent burning, do not measure voltage over 600V!
3. RESISTANCE
Function Range Resolution Accuracy Max
Resistance
4kΩ 1Ω
±(1.0%+5d) 40MΩ
40kΩ 10Ω
400kΩ 100Ω
4MΩ 1kΩ
40MΩ 10kΩ
4. CAPACITANCE
Function Range Resolution Accuracy Max
Capacitance
4nF 1pF
±(3.0%+5d)
4mF
40nF 10pF
400nF 100pF
4uF 1nF
40uF 10nF
400uF 100nF
4mF 1uF ±(5.0%+10d)
