HOLEMAKER HM40AD - Page 11

MAIN BODY ASSEMBLY
11
ITEM PART NUMBER DESCRIPTION QTY
1.1 SPAD40-01-01 MAIN BODY 1
1.2 SPAD40-01-02 BUSHING PERMAGLIDE I 1
1.3 SPAD40-01-03 BUSHING PERMAGLIDE II 1
1.4 SPAD40-01-04 SOCKET SET SCREW M6 x 8 1
1.5 SPAD40-01-05 PRESSURE SCREW 1
01
02
03
04
05
