HOLEMAKER HM40AD - Page 16

SHAFT ASSEMBLY
16
ITEM PART NUMBER DESCRIPTION QTY
4.1 SPAD40-04-01 BEVEL GEAR T=39 ASSY / INCL. SLEEVE 1
4.2 SPAD40-04-02 BEARING NUT 1
4.3 SPAD40-04-03 BEARING BALL 61805 2RS 1
4.4 SPAD40-04-04 EXTERNAL RETAINING RING 25Z TYPE A 1
4.5 SPAD40-04-05 INTERNAL RETAINING RING 37W 1
4.6 SPAD40-04-06 HEX SET SCREW M5x10 1
01
02
03
04
05
