Holland FW2000 - Table of Contents; Introduction; Notes, Cautions, and Warnings

2
XL-FW482 Rev C · 2016-07-05 · Amendments and Errors Reserved · © SAF-HOLLAND, Inc., SAF-HOLLAND, HOLLAND, SAF,
and logos are trademarks of SAF-HOLLAND S.A., SAF-HOLLAND GmbH, and SAF-HOLLAND, Inc.
Contents
Contents Page
Introduction ...................................................2
Notes, Cautions, and Warnings .......................2
Section 1 – General Safety .............................3
Section 2 – Installation ..................................4
Section 3 – Stationary Fifth
Wheel Installation ........................6
Section 4 – Sliding Fifth Wheel Installation .....9
Section 5 – Inspection and Lubrication
Prior to Use ...............................14
Section 6 – Operating Instructions ...............14
Section 7 – Coupling Procedures ..................14
Section 8 – Uncoupling Procedures ..............16
Contents .................................................. Page
Section 9 – Sliding Procedure For a
Sliding Fifth Wheel .....................17
Section 10 – Maintenance Procedures ..........18
Section 11 – As Needed Lubrication .............18
Section 12 – Periodic Inspection
and Adjustment .......................18
Section 13 – Fifth wheel Locking Mechanism
Inspection and Adjustment .......18
Section 14 – Re-Lubricate After Inspection
and Adjustment .......................19
Section 15 – Sliding Mechanism Inspection
and Adjustment .......................20
Introduction
This manual provides you information necessary for
the proper installation of HOLLAND
®
Fifth Wheels.
NOTE: For technical support and genuine
HOLLAND
®
fifth wheel replacement
components contact SAF-HOLLAND
®
Customer Service at:

1.888.396.6501

+86.592.6388.891
Notes, Cautions, and Warnings
Throughout this manual, you will notice the
terms “NOTE,” “IMPORTANT,” “CAUTION,”
and “WARNING” followed by useful product
information. So that you may better understand
the manual, those terms are defined as follows:
NOTE: Includes additional information
to enable accurate and easy
performance of procedures.
IMPORTANT: Includes additional
information that if
not followed could
lead to hindered
product performance.
Used without the safety
alert symbol, indicates
a potentially hazardous
situation which, if not
avoided, could result in
property damage.
Indicates a potentially
hazardous situation which,
if not avoided, could result
in minor or moderate injury.
Indicates a potentially
hazardous situation which,
if not avoided, could result
in death or serious injury.
Read and observe all Warning and Caution
hazard alert messages in this publication.
They provide information that can help
prevent serious personal injury, damage
to components, or both.
