Hollyland Solidcom C1 Pro - Page 28

FR-3
Standard Line Sequence
0B10 Wired Headset Inteace
2-Wire Audio Input & Output Inteace
PGM Audio Input Inteace
RJ451/RJ452 Inteace
PIN1: SPK+
PIN2: SPK-
PIN3: ENC
PIN4: RGB-B
PIN8: MIC1 N-
PIN7: MIC1 P+
PIN6: MUTE
PIN5: RGB-A
PIN9: MIC2+
PIN10: GND
4-Wire Audio Input & Output Inteace
PIN1–PIN8
PIN1 GND
PIN2 GND
PIN3 AUDIO IN+
PIN4 AUDIO OUT+
PIN5 AUDIO OUT-
PIN6 AUDIO IN-
PIN7 GND
PIN8 GND
Standard Line Sequence
PIN1 Transceive Data+
PIN2 Transceive Data-
PIN3 Receive Data+
PIN4 Not connected
PIN5 Not connected
PIN6 Receive Data-
PIN7 Not connected
PIN8 Not connected
PIN1 GND
PIN2 GND
PIN3 AUDIO OUT+
PIN4 AUDIO IN+
PIN5 AUDIO IN-
PIN6 AUDIO OUT-
PIN7 GND
PIN8 GND
Cross Line Sequence
PIN1: GND
PIN3: AUDIO
PIN2: POWER
PIN1: GND
PIN3: AUDIO IN+
PIN2: AUDIO IN-
PIN1–PIN8
Interface pour casque laire 0B10
Interface d’entrée/sortie audio à 4 ls
CASQUE
4FILS
ENTRÉE AUDIO+
TERRE TERRE
TERRE TERRE
SORTIEAUDIO+
ENTRÉE AUDIO- SORTIE AUDIO-
BRO-
CHE 6
BRO-
CHE 6
BRO-
CHE 2
BRO-
CHE 2
BRO-
CHE 8
BRO-
CHE 8
BRO-
CHE 4
BRO-
CHE 4
SORTIEAUDIO+
TERRE TERRE
TERRE TERREENTRÉE AUDIO+
SORTIE AUDIO- ENTRÉE AUDIO-
BRO-
CHE 5
BRO-
CHE 5
BRO-
CHE 1
BRO-
CHE 1
BRO-
CHE 7
BRO-
CHE 7
BRO-
CHE 3
BRO-
CHE 3
Séquence de ligne standard Séquence de lignes croisées
Interfaces
