Instructions – 31110
For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 3
Step 2 – Install Cross Bar
Put cross bar in place and secure
each side using a bracket clamp,
two 3/8” x 1-1/4” hex head bolts,
four 3/8” washers, and
two 3/8” lock nuts as shown below.
Snug tighten but allow for movement.
Repeat on opposite side.
Slide the cross bar into the desired
location and tighten all harware.
GO BACK AND TIGHTEN ALL HARDWARE.
INSTALLATION IS COMPLETE.
