Introduction
Your HOLMAN Retractable Hose Reel uses
a 12mm reinforced hose for added strength
and durability, rated to 1000kPa and includes
a MULTI-FUNCTION SPRAY GUN.
For your information, please read these
installation instructions before using your
Retractable Hose Reel. Please keep all
instructions and refer to them when necessary.
Á Do not leave the tap on–turn tap off
after use and release excess pressure
before retracting back into housing
Overview
a. Mounting Tube
b. Hexagonal Coach Bolts
c. Wall Plugs
d. 180° Wall Bracket
e. Garden Hose
f. Tap-to-Reel Hose
g. Multi-Function Spray Gun
h. Housing
i. Hose Connectors
j. Universal Tap Adaptor
k. Stopper
l. Inspection opening
Contents
Overview 2
Introduction 2
Installation 3
Care and Troubleshooting 5
Spare Parts 6
a
b
c
l
h
d
f
e
k
g
i
i
j
Product Dimensions (mm):
1110H 10m W:330 H:300 L:170 Weight: 3.9kg
1120H 20m W:430 H:370 L:180 Weight: 7.0kg
CH1120 20m W:430 H:370 L:180 Weight: 7.0kg
1130H 30m W:440 H:410 L:220 Weight: 10.4kg
CH1130 30m W:440 H:410 L:220 Weight: 10.4kg
