V-STRUT 916.001.337_001 19
• For maximum grip to the vehicle’s bodywork the head has serrated plates.
• To achieve minimum weight and to prevent corrosion, most parts are made out of anodized
aluminium.
• The base plate can swivel for maximum grip.
• A protection cover can protect the belt against sharp and hot objects.
• A hook fixes the belt to the bodywork of the vehicle.
• A safety hook, mounted to the V-strut or to another V-strut, prevents the device from slipping away
from the vehicle.
• The grip of the ratchet belt can be used to carry the V-strut easily.
• The belt is stored on a belt reel.
3.3 Product identification
Refer to Fig. 2.
/i
3.4 Technical specifications
Refer to Fig. 3.
/i
1 Grip head 7 Handle
2 Mechanical lock 8 Hook
3 Information label, refer to Fig. 1.A 9 Safety hook
4 Cover 10 Identification label, refer to Fig. 1.D
5 Ratchet mechanism 11 Belt reel
6 Tension belt 12 Base
Specifications V-STRUT Value Unit
Weight 7.9 kg
17.4 lbs
Width 149 mm
5.9 inch
Height 210 mm
8.3 inch
Length, minimum (A) 1080 mm
42.5 inch
Length, maximum (B) 1800 mm
70.9 inch
Stroke 720 mm
28.4 inch
Steps 24
Step size (G) 30 mm
1.18 inch
Depth at bottom (C) 220 mm
8.7 inch
Width of grip head (D) 71 mm
2.8 inch
Width of belt reel (E) 149 mm
5.9 inch
