20 916.001.337_001 V-STRUT
/i
3.5 Part numbers
/i
4 Preparation for first use
Check the equipment for completeness and damage. Do not use the equipment if it is damaged; in that
case contact the Holmatro dealer.
5 Operation
5.1 Examples of use
Refer to Fig. 4 and Fig. 5 for examples of the use of one or multiple V-struts.
5.2 Transport
• Carry the V-strut by the handle of the ratchet mechanism. Refer to Fig. 2.
Length of cover (F) 350 mm
13.8 inch
Maximum axial load, symmetrical on head 1600 kgf
3528 lbf
Temperature range -20 / +60 °C
-4 / +140 °F
Country of manufacture China
Specifications Tension belt Value Unit
Maximum load 1250 kgf
2756 lbf
Length 5 m
16.4 ft
Width 50 mm
1.9 inch
Standard NEN-EN 12195-2
Description Part number
V-STRUT 150.062.158
Knife to cut sheet metal 150.062.183
Base support plate 150.011.519
Specifications V-STRUT Value Unit
