TECHNIC
HOLZMANN MASCHINEN Austria www.holzmann-maschinen.at Seite 26
STÄNDERBOHRMASCHINE / DRILL PRESS SB2516H
11 TECHNIC
11.1 Components
No. Specification No. Specification
1 Base 9 Motor
2 Fixing screw table 10 Tightening handle (motor)
3 Release lever 11 Scale drilling depht
4 Table 12 Handle
5 Column 13 Scale angle of table
6 Drill chuck 14 Handle
7 On/Off/emergency-unit 15 Motor pulley
8 Pulley cover 16 Safety-switch pulley cover
