ERSATZTEILE / SPARE PARTS
HOLZMANN MASCHINEN Austria www.holzmann-maschinen.at Seite 47
STÄNDERBOHRMASCHINE / DRILL PRESS SB2516H
No. Specification No. Specification
1 Knob-motor adjusting 23 Seat spring
2 Screw-socket set am10x1.5-12
24 Retainer spring
3 Handle-belt tension 25 Spring torsion
4 Pin-stop 26 Cap spring
5 Ring- Depth stop w/scale 27 Nut-hex M12x1.5-8
6 Lock- Depth screw 28 Head w/pointer and trim
7 Hub 32 Tee wire
8 Guide scale 33 Cord Power w/plug
9 Knob 36 Clamp cord
10 Rod 37 Support motor bracket
11 Lock washer ext. M5 38 Screw hex HD M8x1.25-20
12 Screw pan HD M5x0.8-8 39 Washer 8x16x1.6
13 Box switch 40 Mount motor
14 Screw pan HD M5x0.8-16 41 Cord motor
15 Switch locking 42 Nut hex M8x1.25
16 Screw pan HD M4.2x1.4-8 43 Motor
18 Key switch 44 Nut hex M12x1.75
19 Cover switch plate 45 Lockwasher ½
20 Lead Asm. 3 46 Support motor bracket
21 Screw ser special 10x1.5-27 47 Screw Hex HD M8x1.25-18
22 Nut hex M10x1.5 48 Lever adjusting
