Parts list
Ref.Number Part Number Description Unit
1 TR01
Trampoline frame 6
2 TR02 Trampoline legs 6
3 TR03 Jump mat 1
4 TR04 Elastic springs 36
5 TR05 Net pole top 6
6 TR06 Net pole bottom 6
7 TR07 Net 1
8 TR08 Screws 6
9 TR09 Tool 1 1
10 TR15 Manual 1
TR01 x 6pcs TR02 x 6pcs
TR03 x 1pcs
TR04 x 36pcs TR05 x 6 pcs
TR06 x 1pcs
TR07 x 1pcs TR08 x 1pcs TR09x 1pcs
3
