FAN GRILLE ASSEMBLY
Remove locking nut (08) by turning it anti-clockwise
from the motor shaft.
Place the back safety grille (10) into position. The slots
on the grille should align with the plastic rod on the
front motor cover. If this is done correctly, the safety
grille’s carry handle will be at the top.
Fix the back safety grille (10) into position by replacing
the locking nut (08) tighten by hand. Do not twist the
locking nut too hard.
The groove in the centre of the fan blade (11) aligns
with bolt on the motor shaft to ensure correct
positioning.
Fix the blade into the motor shaft gently by hand, and
tighten the blade cap (09) by turning anti-clockwise
onto the end of the motor shaft.
Mount the front safety grille (12) onto the back safety
grille (10), by hanging the top hook clip of the front
grille over the top of the back safety grille. Close the
clasps all around the grille, finally fit the safety screw
and nut (15) through the hole in the bottom edge of the
front grille and tighten.
1.
2.
3.
4.
5.
6.
OPERATION
Insert the power plug
Speed Control
Speed is controlled by the button switch.
(0=OFF, 1=Low, 2=Medium, 3=High).
To turn the fan on, press the desired button switch.
(1=Low, 2=Medium, 3=High).
Oscillation Control
To make the fan oscillate, push down on the oscillation knob (02)
located on the top of the motor housing. To stop the fan
from oscillating, pull up on the oscillation knob when the
fan is in the desired position.
