Homebase STARDOM - Page 20

Step 16
Place the side burner into the side burner assembly
Align the side burner venture against the valve. Make sure the valve tip goes into the burner venture completely
with good alignment. Then fix the side burner and side burner assembly using M4*10 bolts
Then connect the ignition wire to the side burner assembly.
Q
K
Step 15
K
DD
H
DD
K
Q
lgition wire
Correct
Ignition wire
K
H
D
Q
D
K
D
.
Q
K
D
.
Fix the knob bezel on the side burner assembly
using M4*10mm bolts .
H
D
K
