Homebase STARDOM - Page 21

Step 18
Attach the control knobs to the valve stems. Then remove the igniter cap, insert the 1.5V AA battery
(not included) into the igniter body with the positive ‘+’ end facing out, replace the igniter cap.
Step 17
Place the side burner grate on the side burner assembly and align with the holes.
S
K
S
D
AA电池
AA battery
S
D
D
