FEATURES
PRODUCT SPECIFICATIONS
Engine Briggs and Stratton Q45™
Engine Size 158 cc
Fuel Tank Capacity 0.95 litres
Maximum Pressure 152 bar
Maximum water litres per hour 456 l/h
Maximum water temperature 100 °F (38°C)
Vibration level idling 0 m/s
2
Vibration level racing 6.0 m/s
2
Net Weight 23 kg
DESCRIPTION
1. Storage strap
2. Injection hose
3. Carrying handle
4. Detergent container (not provided)
5. Primer bulb
6. OFF switch
7. Recoil starter
8. Spray wand
9. Spark plug
10. Trigger
11. Nozzle
12. Telescoping handle
13. High pressure hose
14. Shroud
15. Nozzle cleaning tool
16. Axle
17. Hitch pin
18. Shroud screw
19. Oil cap / Dipstick
20. Petrol fuel cap
21. Container (not provided)
22. Spray wand extension
23. Air filter screw
24. Air filter cover
25. Air filter
26. Oil drain plug
27. Slot on trigger
28. Lock out
29. Fuel tank
ASSEMBLY
Refer to figure 2 - 8.
Remove and discard the clear cap securing
the operator’s manual bag to the pump
breather tube.
WARNING
If any parts are missing do not operate this tool
until the missing parts are replaced. Failure to do
so could result in possible serious personal injury.
WARNING
Do not attempt to modify this tool or create
accessories not recommended for use with this
tool. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING
To prevent accidental starting that could cause
serious personal injury, always disconnect the
engine spark plug wire from the spark plug when
assembling parts.
NOTE: Do not start the pressure washer until the engine
has been filled with oil and all hoses are connected.
Running this machine without oil will damage the engine
while running it without water will damage the high
pressure pump.
CAUTION
Any attempt to start the engine without adding oil
will result in engine failure.
WARNING
Petrol and its vapors are highly flammable and
explosive. To prevent serious personal injury and
property damage, handle petrol with care. Keep
away from ignition sources, handle outdoors
only, do not smoke while adding fuel, and wipe
up spills immediately.
OPERATION
WARNING
Always wear safety goggles or safety glasses
with side shields when operating tools. Failure to
do so could result in objects being thrown into
your eyes, resulting in possible serious injury.
WARNING
Do not use any attachments or accessories not
recommended by the manufacturer of this tool.
The use of attachments or accessories not
recommended can result in serious personal injury.
WARNING
Do not direct discharge stream at persons. Failure
to heed this warning could result in serious injury.
15
English
