HOMELITE CHAIN SAW – MODEL NUMBERS UT43102 AND UT43122 − ALL VERSIONS
3
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY
1 34109154G Oil Reservoir Cap .....................................................................................................................................................................................................................1
2 31101573G Chain Cover Lock Knob ...........................................................................................................................................................................................................1
3 33202419G Adjustment Shaft .....................................................................................................................................................................................................................1
4 33301419G Adjustment Pin ........................................................................................................................................................................................................................1
5 33902102G Sprocket ..................................................................................................................................................................................................................................1
6 33302102G Washer .....................................................................................................................................................................................................................................1
7 3290875G Retaining Ring .........................................................................................................................................................................................................................1
8 34111159G Gear Cover ...............................................................................................................................................................................................................................1
9 32203404G Screw (M4.2 x 10 mm) .............................................................................................................................................................................................................3
10 31102573G Adjustment Knob .....................................................................................................................................................................................................................1
11 3290186AG Washer (M4) .............................................................................................................................................................................................................................1
12 34106159-1G Insert ........................................................................................................................................................................................................................................1
13 901212001 Chain (UT43102 — .375 x 52 link, 14 in.) ................................................................................................................................................................................1
901212002 Chain (UT43122 — .375 x 56 link, 16 in.) ................................................................................................................................................................................1
14 660640001 Screw w/Washer ......................................................................................................................................................................................................................1
15 Guide Bar
310625001 (UT43102 — 14 in. with SAFE-T-TIP) .......................................................................................................................................................................................1
310626001 (UT43122 — 16 in. with SAFE-T-TIP) .......................................................................................................................................................................................1
16 308949001 SAFE-T-TIP ..............................................................................................................................................................................................................................1
17 31103573G Chain Cover Assembly ............................................................................................................................................................................................................1
18 33904159G Adjustment Gear ......................................................................................................................................................................................................................1
19 34288154-1G Gasket ......................................................................................................................................................................................................................................1
Not Shown:
34148154G Scabbard (UT43122) ................................................................................................................................................................................................................1
31201154G Soft Case (UT43122) ................................................................................................................................................................................................................1
34113419G Sleeve (UT43102) .....................................................................................................................................................................................................................1
NOTE: The assembly shown represents an important part of the Double Insulated System. To avoid the possibility of alteration or damage to
the system, service should be performed by your nearest Homelite authorized service dealer.
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
CHAIN SAW or when ordering repair parts.
