Homelite UT43102 Repair Sheet

HOMELITE CHAIN SAW – MODEL NUMBERS UT43102 AND UT43122 − ALL VERSIONS
5
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
CHAIN SAW or when ordering repair parts.
PARTS LIST FOR SECTION “A”
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 31100573G Housing Assembly ....................................................... 1
2 36401154G Power Cord .................................................................. 1
3 36301154G Switch .......................................................................... 1
4 33203154G Trigger Spring ............................................................... 1
5 33204154G Lock-off Spring ............................................................ 1
6 34106154G Trigger .......................................................................... 1
7 34107154G Lock-off Button ............................................................ 1
8 36511154G Wire Nut ....................................................................... 1
9 31208261G Oil Reservoir Assembly ................................................ 1
10 34118154G Ring Gear Assembly ..................................................... 1
11 34201154G Inlet Oil Tube ................................................................ 1
12 38202154G Hang Tang .................................................................... 1
13 099918001900 Data Label (UT43102) .................................................. 1
099918002900 Data Label (UT43122) .................................................. 1
14 34101153G Motor Cap (UT43102) ................................................... 1
34103154G Motor Cap (UT43122) ................................................... 1
15 3220313G Screw (M4 x 14 mm) .................................................. 27
16 3220348G Screw (M3.8 x 14 mm) ................................................. 1
17 34210154G Rubber Pin ................................................................... 4
18 36102573G Motor Assembly (UT43102) .......................................... 1
36101573G Motor Assembly (UT43122) .......................................... 1
19 3410302G Cord Clamp .................................................................. 1
20 099928001901 Icon Strip ...................................................................... 1
21 34120154G Front Handle ................................................................. 1
22 34110154G Guard ...........................................................................1
23 34117102G Outlet Oil Tube ............................................................. 1
24 34901154G Oil Pump ...................................................................... 1
25 34105154G Ring Gear Cover ........................................................... 1
26 33205154G Chain Bar Stud ............................................................. 1
27 32201154G Screw (M4.2 x 45 mm) ................................................. 1
28 33904154G Pinion ........................................................................... 1
29 32908154G Retaining Ring .............................................................. 1
988000402 Operator’s Manual
3-24-11
(REV:01)
