HOMELITE PRESSURE WASHER − MODEL NOS. UT80709 AND UT80911
FIGURE A PARTS LIST
The model number will be found on a plate attached to frame. Always mention the model number in all correspondence
regarding your PRESSURE WASHER or when ordering replacement parts.
* Standard Hardware Item – May Be Purchased Locally
NOTE A: Homelite Consumer Products, will not provide engines as replacement parts. Engines are covered through the engine manufacturer’s warranty. Consult the
accompanying engine manual or contact our service department for assistance.
50 561307005 Rubber Foot ............................... 1
51 661555001 Bolt (M4 x 1/2 in.) ...................... 1
52 678600002 Washer (M4) ............................... 1
53 570712001 Rubber Bumper ......................... 1
54 940707082 Danger Label (French) ............... 1
55 940836005 Data Label ................................. 1
56 940617083 Pump Quick Start Label ............ 1
57 940947003 Combustion Warning Label ....... 1
58 940803018 EMC Label ................................. 1
59 940778011 Hot Muffler Label ....................... 1
60 940647047 Choke Label .............................. 1
61 940871002 Oil Dipstick Label ....................... 1
62 940324014 Inquiries Label ........................... 1
63 308662001 Filter Screen ............................... 1
64 308861003 Inlet Tube ................................... 1
65 308862003 Outlet Tube ................................ 1
66 308452002 Detergent Suction Kit ................ 1
67 940473002 Warning Hang Tag ..................... 1
68 940517007 Lubricant Label .......................... 1
69 518932001 End Cap ..................................... 2
70 310650002 Soap Tank Cap .......................... 1
71 678518002 Lock Nut (1/2-20) ....................... 1
72 638275002 Washer (1/2 in.) .......................... 2
73 940608010 Logo Label (Subaru) .................. 1
Not Shown:
* Oil (SAE 10W30, 18 oz) .............. 1
988000369 Operator’s Manual ..................... 1
KEY P/N DESCRIPTION QTY
1 678774002 Lock Nut (M8 x 1-1/4 in.) ........... 8
2 310742004 Front Frame ............................... 1
3 661501007 Screw (1/4-20 x 2 in.) ................. 6
4 940971069 Warning Label (Engine) .............. 1
5 941532001 Logo Label (Homelite) ................ 1
6 310658006 Detergent Tank
(Inc. Key No. 70) ........................ 1
7 660962001 Bolt (M8 x 2.17 in.) ..................... 4
8 638128004 Washer (1/4 in.) .......................... 5
9 308451019 Wheel ......................................... 2
10 620599007 Axle ............................................ 2
11 310704005 Main Frame Assembly (right) ..... 1
12 678899001 Spring pin .................................. 2
13 310703005 Main Frame Assembly (left) ....... 1
14 308910005 Handle Release Knob ................ 1
15 678406010 Bolt (1/4-20 x 3.5 in.) ................. 2
16 678610002 Flange Nut (M4 x 0.7 in.) ............ 1
17 518724003 Spacer ....................................... 2
18 570410003 Cap ............................................ 2
19 678041007 Output Shaft Key ....................... 1
20 NOTE A Subaru 190cc Engine EPA
(UT80709A) ................................ 1
NOTE A Subaru 190cc Engine CARB
(UT80911A) ................................ 1
NOTE A Subaru 175cc Engine EPA
(UT80709B) ................................ 1
NOTE A Subaru 175cc Engine CARB
(UT80911B) ................................ 1
21 940680027 Hot Surface Label ...................... 1
KEY P/N DESCRIPTION QTY
22 940654089 Trigger Handle Warning Label ... 1
23 660592006 Screw (1/4-20 x 2.27 in.) ............ 1
24 940779056 Performance Label .................... 1
25 660592005 Screw (1/4-20 x 1.65 in.) ............ 1
26 570718001 Bungee Cord Assembly ............. 1
27 310673010 Hose Storage ............................. 1
28 308638032 Handle Assembly ....................... 1
29 518929002 Trigger Handle Holder ................ 1
30 940654083 Trigger Handle Warning Label ... 1
31 940705088 Logo Label (Homelite) ................ 1
32 308760017 Trigger Handle Assembly ........... 1
33 308494003 Spray Wand ............................... 1
34 940872001 E85 Label ................................... 1
35 940894001 Danger Label ............................. 1
36 940617045 Engine Quick Start Label ........... 1
37 660760002 Bolt (1/4-20 x 1.85 in.) ............... 1
38 518931004 Spray Wand Holder ................... 1
39 678016006 Lock Nut (1/4-20) ..................... 10
40 308653025 Pump (Incl. Key Nos. 63-66) ...... 1
41 660962003 Bolt (M8 x 2.36 in.) ..................... 3
42 678169004 Thermal Release Valve .............. 1
43 638662021 Engine Plate ............................... 1
44 940786020 Trigger Handle Spec Label ........ 1
45 308835036 High Pressure Hose (25 ft.) ........ 1
46 310667005 6-in-1 Change Over Nozzle ....... 1
47 941505001 Release Water Label .................. 1
48 518391001 Filter ........................................... 1
49 570728003 Injection Hose ............................ 1
KEY P/N DESCRIPTION QTY
