Technical specifications
10 Technical specifications
Device short description:
HmIPW-WGD-PL
Supply voltage: 24 VDC, +/-5 %, SELV
Current consumption: 110 mA max.
Power consumption in
Standby: 0.6 W
Cable type and cross section: Rigid cable
0.12-0.50 mm²
Installation: only in normal commercial switch
boxes (device boxes) in accordance
with DIN 49073-1
Protection rating: IP20
Protection class: III
Ambient temperature: -5 to +40 °C
Dimensions (W x H x D): 96 x 96 x 40 mm
Weight: 131 g
Subject to modifications.
Instructions for disposal
Do not dispose of the device with normal domestic waste! Electron-
ic equipment must be disposed of at local collection points for waste
electronic equipment in compliance with the Waste Electrical and
Electronic Equipment Directive.
Information about conformity
The CE mark is a free trademark that is intended exclusively for the
authorities and does not imply any assurance of properties.
For technical support, please contact your retailer.
