Heating and Cooling (cont'd)
Fan Switch
Turning the switch clockwise will increase the fan speed, and the
fan will circulate warm, cool, or outside air, depending on where the
temperature lever/control dial and function lever/buttons are set.
Whenever the fan is switched on, air flows from the dash corner
vents regardless of function lever/button position.
Function Lever/Buttons
Slide the lever on the DX model or push the appropriate button on
the LX, EX and SE models to direct air to and from the heater,
defroster and vents.
There is an indicator light in each function button that comes on
when the button is pushed.
What the Controls Do:
[DX]
FAN SWITCH
FUNCTION LEVER
RECIRCULATION/FRESH AIR
BUTTON AND INDICATOR LIGHT
AIR CONDITIONER BUTTON
AND INDICATOR LIGHT
(optional)
TEMPERATURE LEVER
[LX/EX/SE]
FAN SWITCH
TEMPERATURE
CONTOROL DIAL
FUNCTION BUTTONS AND
INDICATOR LIGHTS
FRESH AIR BUTTON AIR CONDITIONER BUTTON
RECIRCULATION BUTTON
