CONTINUED
The spark plugs in your car should
be replaced according to the time
and distance recommendations in
the maintenance schedule.
Clean up any dirt and oil that have
collected around the ignition coils.
Disconnect the wire connector
from the ignition coil by pushing
on the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.
Loosen the two holding clips by
turning the heads one-quarter turn
counterclockwise with a flat-tipped
screwdriver. Remove the cover on
the front cylinder bank by pulling
it straight up.
1. 2.
3.
Maintenance
Spark Plugs (6-cylinder Models)
Replacement
271
HHOOLLDDIINNGG CCLLIIPP
